Finished with the right wing, again. And starting on the left

So Spork is at the beach having fun while I’m here slaving away. Since I’d finished the right wing covering, I texted SWMBO to tell him I’d gotten it done. That way he’d know he didn’t have it waiting on him when he got back and to also let him know I was busy working while he was having fun. It was also to brag a little bit that I’d gotten everything done. The immediate reply?

Did you get the fuel tank installed?

Well, no. I’d gone to the house and had dinner instead. So much for bragging.

To install the fuel tank involves a bit of scary work. The tank slips inside a spot made just for it easy enough. But then you have to drill through the end rib of the airplane with three different holes. These holes are somewhat blind as the bottom side of the tank, where two of the holes are to be located, isn’t really accessible. And each hole has to line up perfectly with the corresponding place on the tank where different fittings are screwed in. The instructions, such as helpful instructions are, said “Measure and drill holes. Install fittings.” Um, ok. Thanks for the detailed explanation. Heck, it didn’t even say which fittings to install. Luckily I already knew but I verified with Robby just to make sure.

Before I could drill these holes for the fittings, I had to make sure the tank was installed and wouldn’t move. No sense making the holes align perfectly, only to find the tank had slipped while I was working. Scott had already coached me that rivnuts would be a better solution than rivets and had ordered some in for me to try. I’d never installed a rivnut but it seemed simple enough. Drill a hole, insert a rivnut, squeeze it with Scott’s special tool I had to borrow, then wash, rinse, repeat 15 more times.

Rivnut installed in fuel tank compression tube
Rivnut installed in fuel tank compression tube
Bag for the rivnuts, with part number from Aircraft Spruce
Bag for the rivnuts, with part number from Aircraft Spruce

After working with rivnuts for about 5 minutes, I decided they were the best thing ever. Very simple to install, and now the tank is held down by 8-32 screws instead of rivets that would have to be drilled out to remove the tank.

Tank with rivnuts installed, view through end rib
Tank with rivnuts installed, view through end rib

Here you can see the rivnuts holding the tank in place. This made it very easy to align the tank, and to install and remove it as I worked with the various fittings, tapping, cleaning out chips, etc. Definitely the way to go.

Top view of tank with rivnuts holding it in place
Top view of tank with rivnuts holding it in place

The plans only called for two rivets per side on the tank. I installed four rivnuts per side instead. I don’t think it will be going anywhere.

Now it was time to drill the holes in the end rib. Since I can measure three times and get six different measurements, I wasn’t too keen on measuring to match up these drilled holes as the plans suggest. Instead I grabbed a really small drill bit and guessed about where to drill. I closed my eyes and drilled the first hole through the rib. When I peeked through the hole in the rib, I was about 1/8″ off. Pull back, drill the hole in the new spot. Perfect! With the hole in the rib in the right spot, I simply pressed forward and pecked the boss in the fuel tank making a little dimple to mark where the fitting will be drilled and tapped once the tank is pulled.

I then swapped to a step drill and drilled out the final hole in the rib. In enlarging the hole, I took out the original wrong drill hole so no problem there as my mistake hole ended up on the ground as just some more chips.

Lower sight gauge fitting installed in right fuel tank
Lower sight gauge fitting installed in right fuel tank. It is the brass hose barn thingy towards the back of the wing.

I did the process times three. Two holes for the sight gauges, and one for the fuel pickup line.

I then pulled the fuel tank and drilled out the holes I’d marked to the correct size for a 1/8-27 NPT fitting, then tapped them. Then it was a simple process of flushing all the chips out of the tank and then putting the tank back in place.

Right fuel tank, fully installed with all fittings
Right fuel tank, fully installed with all fittings

Here the sight gauges are in place, as well as the fuel pickup. The front port was plugged, per the manual since I’m using a Rotax engine. I guess a Lycoming must have a fuel return line that would go there.

Right wing covered, left wing ready to start work
Right wing covered, left wing ready to start work

With the fuel tank installed, I moved the right wing up against the wall as close as I could, and then covered it in a tarp to protect it from dirt and the fabric from sunlight. I then dragged the left wing over to the center of the bay and say down on a chair and stared at it a while. We’d spent weeks on the right wing. Would it take weeks to work on the left wing as well? Hopefully we’d be faster now that everything was basically the same.

I started by removing the left wing slats from when we’d mated the wings to the fuselage. That took a bit of doing as a bolt had jammed behind some sheet metal and damaged the sheet metal. There was nothing to do but to cut it out and move forward, which is what I did. It isn’t a critical area and it will be behind the slats so not really visible. With the slats removed, I could either start prepping for covering, or I could work on the fuel tank. Since I had all the parts laying right there, I decided to work on the fuel tank. It took about 2.5 days to get the compression tubes installed and shimmed, the tank installed, the fittings installed, etc on the right wing. Plus I had Spork and Cody here to help me. Now I was by myself. I flipped the wing over, started on the compression tubes, and before I knew it was at this point.

Left wing tank fully installed
Left wing tank fully installed

It took me about four hours from drag the wing out to done. 1/2 day vs 2.5 days, and that 2.5 doesn’t include the trips to the airport to ask Scott questions or borrow tools, or texts to Robby, or trips to the store. That 2.5 days actually took about a week. Yeah, maybe this wing will go a bit faster.

So this is where we are today. I can only cover one side of the wing. The magnetometer from GRT was DOA when it arrived so I need a new one before I can close the wing up. I lost most of last week because GRT shut down for Oshkosh. Today is Tuesday and I don’t have high hopes I’ll get a call back today from GRT despite my email and phone messages asking for help. (Can you tell I’m getting pissed?) Today I’m doing some farming stuff, then working on the plane this afternoon. I have some new zip ties coming from Amazon today which I want to use to secure all the runs in the fuselage instead of the plain plastic ties I used already. So when they show, I’ll cut off the old and install the new. Once that is done, I have the choice of starting to cover the fuselage, or starting to work on the panel. I’ll be stopping by Hudson’s today to grab some lexan to start on the panel anyway and panel work is a lot of head scratching so I’m leaning towards that. Once GRT calls me, I’m going to get them to quick ship the parts I need and then hopefully I’ll have the boys here to start working on covering the wing.

Once the left wing is covered, we can start on the paint booth and covering the fuselage. Then it is on to painting. After painting, the gear goes on and it is time to make airplane noises. Vroom vroom!

It is done! Well, one wing anyway



Wing with leading edge final tape nearly installed
Wing with leading edge final tape nearly installed

We’ve not had a lot of updates to the blog lately. There are a few reasons for that. One, we are covering the wing.

And covering the wing.

And covering the wing.

There is only so much to say about that.

I was told that after we’d covered one wing, we’d have the hang of it. I was doubtful but I have to say after covering one wing, I think I may have the hang of it. We made a few little mistakes here and there, but overall the wing came out better than I would have expected. More importantly, I’m at the point where I feel like I can make a mistake and fix it. Not as in strip off all the fabric and start over from scratch fix it, but just fix the wrinkle, bubble, etc, and move on like it was never there. What is that saying? A professional knows how to hide his mistakes? Something like that.

We had a brief interlude in the airplane build this month. The Spohns and our family both took a vacation along with Grandma, who was the ring leader, to Grenada and St. Vincent and the Grenadines. It was an epic week and a chance for me to sail the Southern windward islands, which I’ve never done. We had a great crew and everyone had a large time.

After being gone for a week, it was tough to get back in the groove. Between all the to dos waiting when you get home and being out of the habit of working on the boat (and working period) it took most of the next week to finally get back in the shop.

While I was gone, the avionics from GRT Avionics showed up. Dustin grabbed them for me and put them in the shop. I eagerly opened the box of goodies to see what had shown up. Sadly, I was a bit disappointed. The EFIS looks perfect. But the engine monitor was for a Lycoming, not a Rotax, which is what I ordered. Also the autopilot servos showed up, but no mounting kits or hardware. Apparently I was supposed to know I had to order them separately. The last straw was when I went to install the magnetometer. This needs to be installed in the wing so we can cover the left wing next week. I noticed a rattle coming from inside. I opened to case to find that two of the elements of the circuit board were never attached to the board. They are wired, but not physically attached and secured making the magnetometer useless as it will break probably by the second flight. I emailed and called GRT, with no response and no way to get a person on the phone. Eventually I did receive a call back from a very nice guy who informed me that my magnetometer would need to come back to them and that they shut the company down for the week, for Oshkosh. So next week, sometime, I should be able to get it handled. Argh!! I have a wing I need to cover and I’m losing two weeks, plus shipping, for one stupid magnetometer.

Who shuts down an entire company and doesn’t put a notice on the website or on the answering machine? I was very excited to use GRT. So far, I’m less than impressed.

Magnetometer mounting plate installed in wing
Magnetometer mounting plate installed in wing

Before I knew the magnetometer was bad, I made up an install plate for it out of .020 aluminum. I needed to span the lightening holes in the rib. I also planned on putting the magnetometer inboard on the wing rather than on the wingtip as recommended. The strobes are going to be installed out on the wingtip and I was worried about the pulses of electricity messing with the very sensitive magnetometer. By installing it in this location, I was able to run the wires back to the fuselage tied to the pitot tube which was already carefully run through grommets with some extra room.

Magnetometer temporarily installed in wing
Magnetometer temporarily installed in wing, with service loop.

By this point I knew the unit was bad, but I got it installed anyway as I was stuck on anything else to do.

Patch in brand new wing covering
Patch in brand new wing covering

While I was sorting out electronics and warranty returns, Spork was steadily working on the wing. During out work, we noticed a small blemish in the fabric on the top of the wing. We’ve been very careful around the wing so I can only assume this was a factory defect that appeared when we tightened the fabric. Regardless, it needed a patch as the entire wing was covered at this point. I researched in the SuperFlite manual, and online, and couldn’t find any decent information on making a patch. I knew it was basically a doily like we would use on the inspection rings, but what I couldn’t find was if I should shrink the fabric after installing it. The purpose of the patch is to cover a hole. But the base fabric is already shrunk. So do I attach this patch, then shrink it too? Would that cause a pucker in the base fabric? If I don’t shrink it, then the patch isn’t really taking any load.

Finally I reached out to Scott who assured me, yes, shrink the patch but only to the first temp (250 degrees). Patch installed we went back to work.

Doilie over lone rivet on outboard edge of wing
Doily over lone rivet on outboard edge of wing

Spork is very meticulous when he works on the covering, which I appreciate. While he was working, he noted that one rivet was not covered by any of our finish tapes. Something we’d all missed up to this point. With our patching experience firmly in hand, Spork cut out a quick doily and made a one piece finishing tape for this lone rivet. This one did not need to be shrunk like the patch job required.

Header tank plumbed and installed
Header tank plumbed and installed

While Spork was working on the wing, I set about working on the fuel system. I’d had Scott order some hose for fuel lines prior to ordering the firewall forward kit. I didn’t even think about the kit having its own fuel lines, but of course it did.

Regardless, I’d already run the Aircraft Spruce supplied fuel line through the fuselage so I just stuck with that one. Except when it came time to install everything, I couldn’t get the fuel line to go onto the barbed fittings. It was REALLY tight. I looked at the ID of the lines, and the one I was using actually looked a bit bigger than the kit supplied fuel line so it should work. I tried again. I cursed, I went to EAA tech tips, I went to YouTube. Finally I called Scott and asked him why I couldn’t get the fuel line on He couldn’t answer, but he said he’d drive up during his lunch hour and look for me. I was floored. I didn’t expect a house call from an A&P. I’m always surprised that he even answers my phone calls. But during the conversation with him, it occurred to me that maybe I should try the kit supplied fuel line, even though it appears smaller.

Turns out, the fuel line that comes with the kit is a much more supple line, with less reinforcing. It slipped on like butter. I’d spent the morning nearly breaking things trying to force the wrong line onto the fittings. Once the new line was installed, it took about 10 minutes to do the entire job. Duh.

Fuel lines and their final routing under the fuselage
Fuel lines and their final routing under the fuselage

With the header tank plumbed, I went back and with a combination of Adel clamps and zip ties, secured the fuel line and the return line in place. The lines are just hanging off the front at the firewall waiting for the engine install.

FedEx freight truck
Presents, for me?!

Before I left for Grenada, I ordered the Rotax 912 engine that we are going to be using. It will most likely sit in the crate for several months, but at least it will be on hand and ready to install should we make progress on the build.

Shiny and new Rotax
Shiny and new Rotax

One of my original goals with this airplane was that it would be powered by a Rotax. I wanted to fly behind a modern aircraft engine, with proper ignition, no mixture, and the ability to operate off of automobile gasoline, or MOGAS as it is called in aviation. This lets me get gas from my normal source and keep it here at the farm vs having to find 100LL aviation fuel and get it here for twice the price.

The last piece of the puzzle, besides the many hours of labor it will take to build this airplane, is the propeller. I have one coming from Robby as well that will surely be hanging on the wall well into this winter. But when that arrives, all the major pieces of the puzzle are on site. Now it is just up to Spork and I to assemble everything.

Beginning the installation of the inspection rings
Beginning the installation of the inspection rings

While I was working on all the bits and bobs, Spork had been making progress on the wing. I came back over to go over the last bit of finish taping and helped him finish. Then it was time to move onto the inspection rings. As with most elements of this build, there was some trepidation over doing this for the first time. What if I put them in the wrong place? What if they don’t stick? As usual, reality turned out to be far less scary than imagination. We had the other wing sitting directly beside this one, completely uncovered. Spork and I spent some time making sure all the rings were in the correct spots, then we marked them and started cutting out doilies.

Eventually Spork took off to the beach for the last summer vacation before school starts and Crystal and I worked on the inspection rings. Scuff the rings, glue the base of the fabric, glue the rings, wet the base glue, stick the ring in place, then cover with a doily. Move onto the next ring. It took about two hours to install them all.

Right wing, covering finished!
Right wing, covering finished!

The tapes are all in place. The trim work is done, all the little bubbles and wrinkles have been addressed, and the inspection rings are installed. This wing is covered!

Today I’ll install the fuel tank, then move this wing over to the side and carefully cover it to protect it from light and from getting damaged. Hopefully the left wing will go much faster since we now have some experience doing this. We can’t get too far ahead of ourselves, because I have to wait till the magnetometer shows up to cover the left wing. But I can at least cover one side of it. Plus there is a ton of prep that has to be done to the wing itself. Scotch brite, cleaning, etc. Luckily Spork and Cody will be here soon so they can get to work on that portion while I go to work on the panel and the autopilot servo install.

Once the left wing is covered, it will be time to build the paint booth. While that is being build, we should be covering the fuselage. Once it is covered, it will be time for paint. Once paint is done, we can mount the fuselage on the landing gear and finally have a rolling chassis which means sitting in the seats and making airplane noises!



Airplanes and Poetry

I have been recently been informed that one way to write a speech is to think of a couple adjectives that describe a subject and write about them. Personally, that sounds like poetry but I’ll give it a shot. When I think of covering the first two adjectives I think of are fabric, and toxic. Lets see what I can do with them.

The fist adjective is fabric. One of the most prominent aspects of fabric is that it is final. By final I mean it is the outermost surface besides paint. Whenever I worked on metalwork on or in the body of the plane, it was ok if part A is slightly longer then part B.  Now, if the fabric has a wrinkle in it, it is going to be visible from the outside. At the same time, it feels nice to almost be doing something that is final because it means that I’m not going to have to take it off seven times before it is finally on to stay.

Last and least is toxic. I think of the word toxic when I think of the glue that is used to stick the fabric on the metal pieces of whatever piece you are covering because it smells bad and it messes with my head. I don’t know why but smelling the glue actually makes it harder for me to think. Readers might be wondering why I keep bringing glue up. Someday, somebody will run the numbers to find out the exact fabric to glue ratio, but I am certain that I have used more glue, in my life, than I have duct tape. I’m a farm boy! I use duct tape like it grows on trees! I should not have used that much glue just covering a wing and some tail feathers!

I know I have said this before but I am going to say it again. Building an airplane is loads of fun and a great learning experience. Now I am going to attempt a Diamante poem about glue. “Thick, Thin” ,describes the different amounts of Acitone you add to the glue depending on what you plan on doing with the glue.



Glue

Sticky, Green

 Evaporating, Running, Withering

Tacky, Tremendous, Thick, Thin

Drip, Blop, Plop

Choking, Wheezing

Death

The wing is coming along nicely

Cody gluing up the tapes on the wing
Cody gluing up the tapes on the wing

We have a stomach bug going around the house. It started with Cody, then progressed to The Princess, and then today it hit Spork who was down for the count for the day, never getting out of bed or very far away from a throw up container. Poor guy.

The weather was epic so we enjoyed a cool day in the shop with a nice breeze provided by the fans. The fabric was already on, but the tapes needed to be done. But before that, the tail wheel shock needed to be finished, which meant fitting the access panel we made to the shock dimensions. Cody knocked that out in no time and we moved onto taping.

As we progress to each portion of the build, I always worry what the next part will be like. Will taping be really hard? What about hanging the engine? What if I mess that up? Or the wiring for the avionics? What if I let the smoke out and ruin the avionics. There is always a little trepidation at each new step that I will come up short on knowledge or talent. Taping was, oddly, one that I was worried about. But with Cody’s help, we got started and found that it was, as promised, decidedly easy. It is tedious, but really it is just an arts and craft project. Lay out some lines, spread some glue, lay out the tape, spread some thinner glue, move on to the next part. It is actually quite enjoyable and begins to make the wing look like an airplane wing.

Of course, the next step is inspection rings. And I’m already worried about them. Even though I’ve already done one once before at an EAA workshop. It has been several years. Plus, what if I put them in the wrong place?!

We’ll get there, and get it done somehow.

Wednesday is our next work day. Hopefully we’ll have everyone healthy and be able to work. We need to flip the wing and tape the other side. Then we’ll tape the edges and the wing will be covered! Then we’ll use the uncovered wing to locate where our inspection holes should be and cut in the holes (scary!) Once the inspection holes are in, we’ll move this wing to another shop bay and start on the next wing. Hopefully we can get this wing done in a much shorter time frame since we now have some experience. I’d like to at least get it wrapped by Friday if possible, maybe even a tape or two in place.

Once the second wing is done, which will probably take about a week, we can move onto covering the fuselage. We are doing that last because I am waiting on avionics to show up and I need to install autopilot servos before covering. There is no provision for an autopilot in the SuperSTOL build so we’ll have to make it up as we go. Should be interesting.

Huge multi day update

Based on the blog, you’d think we haven’t been working on the plane. Quite the opposite is true. We’ve been working nearly every day, with little time left over for documenting the build. When we last left off, Spork had completed the battery box and installed it.

Battery box with cables installed
Battery box with cables installed

We added a simple 24 gauge cable to provide for a battery condition monitor LED, a feature of the EarthX battery. The problem was we didn’t have the correct connector, despite ordering an entire set of connectors for airplane builders. We had every connector in the world, except the one we needed. Luckily Scott bailed us out, again, and got us the connector we needed. Here you see the cable, with a service loop installed.

ELT cable installed, and labeled
ELT cable installed, and labeled

Since we had the correct connectors, and we had our new label maker, we also ran the ELT cable for the cockpit remote switch. We labeled the cable so that when the time comes,  we won’t be wondering which white cable this is.

right wing, ready to break down and start covering
right wing, ready to break down and start covering

We had a lot of false starts on covering our first wing. We had to install the compression tubes for the fuel tank, we had to paint the spoilers three our four times, I lost count, and we had a number of parts we had to go get or special order in. We lost several days due to these issues.

Spoilers sandblasted and prepped for paint
Spoilers sandblasted and prepped for paint

I fretted over whether to sandblast the spoilers for a few days. Luckily I decided to do so because we ended up sand blasting off our paint several times and starting over. We started with an automotive style rattle can primer and paint. When that proved to be too fragile we went to an epoxy based primer, PPG brand from Single Source here in town. While I was at it, I painted the locking collars from the tailwheel, the little circles you see beside the spoilers.

We also used the belt sander to break the corners of the spoilers and the edges. Corners and edges are the first places to loose paint and these things will be sticking up into the wind quite a bit so I wanted to make sure the paint stayed in place. Rounded edges will help quite a bit.

Missing hardware for the flap system
Missing hardware for the flap system

With the compression tubes nearly installed, we came across a problem. We didn’t have a simple little bracket that is installed on the hardware for the fuel tank and holds the flap return spring. We also didn’t have the bolts that held the bracket. I called Amy at Just Aircraft and she had the needed hardware going out the same day, along with a firewall forward kit I’d ordered a few days before from Billy at Plane Fun Aircraft. Everything showed up literally minutes before we ran out of parts and had to stop work. With hardware in hand, we were able to install the flap return spring, the compression tubes, and temporarily mount the fuel tank. Everything went in just like it should, at least after we thinned out some of the shim washers for the fuel tank.

Rivets won't work for the fuel tank
Rivets won’t work for the fuel tank

Once the compression tubes were in the wings I checked with Robby to see how he mounts them. “Some people use screws but I just rivet them in place. They are easy to drill out.”

I liked the idea of riveting them, but looking at the needed dimensions I saw that the CCP-44 rivets were not going to work. In desperation, I went to visit Scott to see what he thought I should do. “Rivnuts” was his answer. We ordered some, along with screws, to be delivered this coming week. With rivnuts in hand, we’ll install them and then install the tanks. These are an even better solution than rivets as we will have simple screws to remove the tank should we need to at some point in the future.

Spork sandblasting the spoilers, again
Spork sandblasting the spoilers, again

As I said, we had several in and outs with the spoilers but it was ok. I needed some practice painting and the spoilers were a good item to practice on. A small mistake could be sand blasted off in a few minutes and the could be repainted with a small amount of materials.

Right wing with covering beginning to be applied
Right wing with covering beginning to be applied

With the several setbacks behind us, we finally started covering the wing. About this time, we had a stomach bug start working its way through the house putting both Cody and Spork on their butts. I spent an entire day working by myself on Saturday and made good progress on the wing.

Spork gluing up the fabric to prep for cutting out the spoiler slots
Spork gluing up the fabric to prep for cutting out the spoiler slots
Taught fabric and holes burned through for rivets
Taught fabric and holes burned through for rivets

When the fabric is installed, we burn holes through the ribs in spots pre-drilled. These allow us to install large headed rivets for holding the fabric in place. This is fun because it is so easy, and terrifying because one wrong move and you burn a hole through your fabric. Scary!

The paint shows up, Superflite's system
The paint shows up, Superflite’s system

While we were doing all this work, our paint showed up for the airplane. These few cans of paint is what $3000 worth of paint looks like. Good thing I’m a master painter and won’t make any mistakes. Yeah right.

To do list from the past two days
To do list from the past two days

This is a bit of a disjointed update. Lots was done but it was all given short shrift in this multi day post. We’ve been going from can to can’t these past few weeks, trying to get as much done on the plane as possible, while still maintaining a farm, having two renters move out the same month, and still doing work at the Civil Air Patrol. It has been fun. Our status today is the right wing is covered, minus the final heat shrink and tapes. Once those tapes are done, we’ll move the wing to the next bay over and cover it to protect it from the sun. Then we’ll start on the left wing and wash, rinse, repeat. Once the left wing is done, hopefully this week, we’ll move that wing out and we’ll have room for the paint booth to be built while we start covering the fuselage. When everything is covered, it will be time to paint, sand, paint, sand, etc.

Once the painting is over, we’ll bring all the pieces together and remount the wings and take the fuselage off the stands for good, putting the plane on its gear. With wings and gear, we’ll hang the engine which should be here by then, and then it is time for the avionics.

Then it is time for final assembly! That will probably take two months but whatever, it is something to dream about.

Our shop pet, a little frog
Our shop pet, a little frog

Hopefully our perennial pet, Mr. Frog, will still be around by then so he can see our creation come to life.



About to Start Covering

One third of building an airplane is covering. Covering is when you put the fabric or aluminum on the skeleton of the plane. Since we are building a Superstol, we will be using fabric. The covering process involves painting multiple layers of glue on the metal bars that are going to touch the fabric, laying pre cut fabric on whatever part of the plane your building, applying some glue on the fabric where the metal bars are touching the fabric and, finally, ironing the fabric. Ironing the fabric makes the fabric shrink and become taught, which makes it stronger and more aerodynamic. It makes sense, then, that covering is one third of building the plane. Although my dad and I have not started covering, it should only be a matter of days until we unroll the fabric. After that, all we have to do is the avionics, engine, cowling, wire the ELT, cut and install the windows, fasten on the main wheels and, the big one, paint the fabric. If my dad’s calculations are correct, we are 65 to 70% done.

The battery box is done

Today was the day of the Spork. Almost all of our projects for the day revolved around finishing the battery box. I did small things around the shop and a few small things to the airplane such as tidying up the ELT antennae.

ELT antennae with holder in place
ELT antennae with holder in place

I had some surgical tubing hanging around the shop from a sling shot project we’d done years ago. It is soft rubber that combined with a zip tie gives a good vibration friendly hold of the top of the antennae keeping it from whacking into things in the tail during flight.

Milling the slot in the battery tray
Milling the slot in the battery tray

I also added a small contribution to the battery box by milling the slot in the tray for the hold down straps. Not because Spork couldn’t do it but it was a good division of labor at the moment so I knocked it out.

Spork with his masterpiece, a completed battery box
Spork with his masterpiece, a completed battery box

But other than milling the slot and a sometimes helpful bit of advice here or there, this battery box was entirely Spork’s creation, from concept to template to fruition. He even did all the installation in the airplane. And it fit perfectly! Just the right amount of hold down tension, perfect brakes on the metal. It looks really good and he learned a lot.

Battery box and battery installed in the airplane
Battery box and battery permanently installed in the airplane

You don’t really notice it there, but the ground cable is complete and laying against the bulkhead. The hot lead is hooked up to the battery and the ground is bolted to the airframe but not connected to the battery, keeping the angry pixies from flowing and creating any sparks.

The weight savings for this battery vs. a normal battery is amazing. I have pretty much the same battery in a traditional lead acid battery and it weighs probably 30 pounds. This one weighs about 3-4 pounds? When you pick it up, it feels like an inert sample battery like you’d see on display. The shell is there, but none of the guts. It is kinda weird.  And it has slightly more amperage and higher voltage than the other battery I have on hand. It does cost about 4 times as much, so there is that, but when every pound counts, this is a huge weight savings. It also means we could make the battery box out of lighter material as well, saving weight there as well as work since thinner metal is easier to work.

Battery cable run to the front of the airplane
Battery cable run to the front of the airplane (its the white thing running towards the camera)

With the battery installed, we could proceed onto other battery related items like running the power cable to the front of the airplane. This was a simple run as the wings have been removed and the fuselage is back on the rotating stands in prep for covering. So it was a simple matter of running the cable to the front, measuring the length we needed, and cutting off the extra (which became the ground lead). Then I taped the last terminal to the end of the cable so when it is time to start working in the cockpit, we will mount the master relay, then terminate this battery cable and attach. Voila! Instant power to the cockpit.

The cargo door, with all the hardware removed
The cargo door, with all the hardware removed

While I was snapping pictures, I realized that I really didn’t have a good picture of the cargo door we made once everything was finalized. Here you can see the frame within a frame that we made, plus the holes drilled for the hinge and for the drip guard. The bottom looks a bit green because it is. I had to file down a bit of the metal to get the Hysol filed smooth. So that is primer to protect the exposed metal. Once I get the painting equipment setup, I’ll go back and primer the entire door frame as there are nicks and bumps here and there from our work. This will be an area that gets banged a lot so it will need some extra protection.

To do list from 6-24
Now that is how a to do list should look!

Technically this is the to do list from the 23rd. That is the day we called an audible and did the butt ribs instead.

With the box completed and installed, we knocked out making and running the cables. I also adjusted the tailwheel lock so it works much better now.

Today I’m supposed to receive a box of aviation grade electrical terminals. Those should allow me to install the battery condition cable which basically blinks a light on the panel to alert you to the battery state. I’ll also be able to install the ELT cable as there are some terminals I need for that. Once those cables are installed and everything zip tied in place, it will be a once over of the fuselage to inspect for any dinged powder coat and a thorough cleaning. With everything touched up and clean, the fuselage will officially be ready for covering. I guess I should enjoy this to do list because the next one will say “cover airplane” and be the same for about a month. Not really, but close enough.

We’ll actually cover the wings first, because we need them done and out of the way so the paint booth can be constructed. I should pick up some box fans for that as well, now that I think about it. Done, gotta love Amazon. With the wings covered, we can then go to work on the covering the fuselage. Once that is done then it is time to start painting, something I know very little about. Oh well, this is supposed to be a learning experience. I’m sure it will be.



A short day yields major unexpected progress

To do list for 6-23
How we start each day in the shop

Each morning I try to take the supplies we have, the supplies we need, the instructions I’ve read, the parts that are ready to install, and the page of the manual I happen to be on at the moment and condense it down into a to do list for the day. We never get the entire to do list done in a day. That isn’t the point. The point is we both, or if Cody is here, all three of us know what is on the agenda and if you don’t know what you are doing, then refer to the list.

Today when we got up, it was battery day. Finish the battery tray. Make up the cables. Install the battery tray, etc, etc. The battery had been all over the to do list for the past several days, so today was our day to get it finished.

Spork breaking metal for the battery tray
Spork breaking metal for the battery tray

Spork had been working on the battery tray for several days off and on and today was the day to start braking metal.

As with most plans, the template didn’t exactly fit in the brake so there were a few last minute adjustments.

With the tray itself made, we were discussing making the straps that will secure the battery into the tray when a combination of events and available personnel allowed us to call an audible. We bagged the battery tray and instead elected to work on the butt ribs. Getting the butt ribs done would put us back to plan A, which meant getting the wings off the airplane and onto the stands for covering. This would allow us have much better access to the fuselage for the rest of the work we were doing to the battery and other things like the ELT. It would also allow us to split our duties, with someone beginning to work on the wings.

With all hands on deck, including the girls in the store, we switched gears and did a mad dash to get all the butt rib work done prior to rolling the airplane outside. That included taking a couple of read throughs through the instructions on how to do it. Once everything was ready, we took the airplane outside and unfolded the wings.

Slat and boot rib taped in place
Slat and boot rib taped in place

It is amazing how simple something goes when you have lots of help and all the prep work has been done. It took us about two hours to go from rolling the airplane outside to rolling it back inside with the ribs fully installed. We had not one mistake and everything went relatively smoothly.

Dan drilling out the butt ribs standoffs
Your author actually getting in a picture for once.

Once the butt ribs were squared away, we removed the wings and put them on the stands. We then rolled the airplane back inside and shut the door. It was beginning to get a bit hot by this point so there was a celebratory watermelon cut open (thanks Miguel!) and everyone got a few pieces.

Spork eating watermelon and cooling off
Spork eating watermelon and cooling off

We needed to go swap some battery terminals out for the correct ones, and we needed some odds and ends from the hardware store. By this time it was 2pm, hot, and we’d been at it since 6am. We decided to spend the afternoon running errands and cleaning up and getting ready for church instead of working on the battery.

To do list for 6-23

It was a relatively short day, but I’d planned on getting the butt ribs done on Monday so technically we are a couple of days ahead of schedule. We should be able to knock out the rest of the to do list tomorrow and be onto covering starting on Monday. That is at least one day ahead of plan, possibly two.

Technically we only crossed two things off the list today. Install magnetic catch on the shop door and install butt ribs. But in reality we’ve nearly finished the battery tray and the rest of those battery related items should go quickly. We picked up a battery terminal crimper yesterday at Agri Supply so making the cables should go easy enough.

I also found out that we don’t need to run the wingtip lights now and we can wait till after covering and painting so that item will get moved off the list. Also the gauge for the LED light has been determined. It is 24 gauge which I already have on hand.

My terminal kit should be here Monday so I can hook up the LED light cable, zip tie everything together, and put the tail of the fuselage back onto a rotating stand. At that point, we are ready to start covering. While I’m waiting on the terminal kit to arrive, we can start prepping the wings so Monday should be a busy day.

Haste makes waste

Messing up, especially for a type A, pilot type, is devastating. All you can hope is that no one noticed. Unfortunately (actually fortunately) I have Spork (and in this case Cody) alongside to see me mess up. But at least they are family so we’ll keep it quiet.

Except trying to be an example to Spork in my blog post timeliness, I’ve also blogged pretty much every day on the build. Yes I’m supposed to blog every day, but I don’t always do it the same day or the next day. There is some time between the action and the post so I have time to learn a bit and maybe edit out the worst of my mistakes. But in this case, I blogged the same day, documenting for to the world my mess up. Yesterday it all came to light.

I’d blogged previously about trying to install the butt ribs, and what a pain in the butt that turned out to be. The root cause of that failure was that I thought we were simply taping the slats in place, not actually installing the slats. So we’d pulled the airplane outside, on a day forecast to reach 100 degrees, with the idea that we’d tape the slats in place, knock out the butt ribs, and be back inside before it got hot.

When I found out that we actually had to install the slats, not just tape them in place, I didn’t want to take the time to go find the section of the manual that explained how to install the slats. I figured it was just temporary anyway, I can get them in quickly. Plus the slat section was buried in the wing build section. Since I didn’t build the wing, I really don’t know my way around that section as well. Time was a wasting and I had two boys standing there ready to work. I didn’t want to spent the next 30 minutes reading. So we went straight to work.

Then the bolts didn’t easily fit into the bearings that hold the control arms on the slats. Hmm, odd. But having to press a bolt/pin into a bearing is normal. You want the bearing to spin, not the bearing on the bolt itself, that causes wear and eventually failure. So we pressed in the bolts which was a pain and later caused me to use a slide hammer to remove one. Finding out the slats were labeled wrong was simply the icing on the cake the caused the entire day to go sideways.

So yesterday I sit down before work begins and open the manual. Lets see what it says about installing slats….

Slat installation instructions
The paragraph that could have saved an entire day

I’ll save you the squinting. Sentence two says, “The AN 3-20 bolts will have to have the cad plating removed to fit into the bearings properly, the head of the bolt should bottom out on the bearing without putting any pressure on it.”

Sigh

It never occurred to me to remove the protective cad plating, since its, um, protective. I took a small set of bolts, pressed the bearings back off with the hydraulic press, and took them to the belt grinder where I Scotch brited off the cad plating. They fit better. I worked them a bit more, the bearing slid on smoothly but didn’t seat on the head as described in the instructions. I moved to the small belt sander and a fine belt, touching up the area around the head. Butter.

Now I could install the slats with relative ease, inserting and removing the bolts as needed. With now proper hardware, I installed the slat I’d relabeled the day before and prepared to move forward. Except it was the wrong side! How could that be?!

I didn’t have the slats labeled wrong, I had the sets wrong. I thought we had inboard and outboard as sets, No, we had left, and right as sets. Which meant that the label I’d so carefully checked to make sure was wrong, was actually correct. Those were the left wing slats, inboard and outboard. I’d just installed one on the right wing.

Sigh

All of this had been for nothing, because I was in a hurry to beat the heat.

So, after much swapping around and grousing, I installed, along with the help of Spork, both inboard slat sections, and taped them in place. I then made sure to label the outboard slats and put them away. What has taken two days should take about an hour next time. Lesson learned, it’s better to stop and understand what you are doing rather than press on (pun intended).

Wings spread as best we can in the shop
Wings spread as best we can in the shop

Had we beaten the heat that day, we’d have pulled the wings off and put them back on their rotating stands. Now we have to work around the wings in place. Spork came up with the idea to spread them partially like in the picture. We bubble wrapped the wing tips and tied off the wings to each side so we have access to the fuselage. It is much better than working around the wings in their stowed position. Good call Spork!

The ELT antennae mounted in it's final postion
The ELT antennae mounted in its final position

After checking with Scott to verify that this antennae does indeed ned to be grounded, I switched up my plan and went back to the method suggested in the manual for this antennae. My concern was the tip of the antennae is going to rub the fabric or bang against the fuselage members, but with some careful planning I was able to get it to fit very well and not bother anything. I hope.

Spork mocking up the battery box
Spork mocking up the battery box

Spork spent the day, and I mean the entire day, working on a battery box. I’d forgotten to order one, so no problem. We’ll just make it!

Making a template and then transferring it to metal is a new skill for him. He worked very diligently and very hard. He also was not accepting of any errors or mistakes. The end result is after nearly a full days work, he is still making the template and hasn’t cut the first piece of metal yet. He’s getting close, but by about 3:30pm (we started at 6am) I could see he was wearing out on this one job.

We took some time yesterday to run some errands and do non-building stuff. We went to Angie’s for lunch, stopped by Loop Road Auto Parts and Lowes to get some supplies and even stopped and picked up some salt for the pool. By the afternoon we were both wearing out a bit. I sent Spork home to unload the 600 lbs of salt from the truck and then to work on his blog post in the A/C. I went upstairs and turned on the A/C myself in order to work on the ELT plug wiring. I spent about 2 hours going over the schematic, getting my work area ready, and then soldering. The end result?

Wired D Sub connector
My very first D-sub connector, perhaps even wired correctly

This was tedious work. The connectors are VERY small, so small I have trouble seeing them. But I think I was able to get them wired correctly and the heat shrink all looks good. A little finish work and this connector will be closed up and plugged into the ELT so we can run the wire to the cockpit. Another task to complete before covering.

So despite the setbacks the past few days, we are actually making good progress. Many of the items on this list revolve around getting the battery box made and the battery wiring installed. You can see Cody written by a number of the items on the list. Those are things we are waiting for Cody to come back for, although if we make enough progress we may coerce Miguel to help us and then we’ll tackle the butt ribs ourselves on one of these cooler days coming up. We have about 5-6 work days before Cody shows back up, so yeah, we’ll need to get the butt ribs installed before he gets here, and then remove the wings and get them prepped for covering.

I also want to look at what it would take to make a bike mount for the wings.

Bikes mounted to wings
It isn’t as crazy as it looks

A bush plane, that lands pretty much anywhere, with a couple of mountain bikes slung underneath, makes for a pretty useful critter. Even if all you are doing is going to a fly in. Word is it only costs a couple MPH and they ride under there deceptively well. We’ll see. Up to this point, I’ve not wanted to make any changes to the kit. And I probably won’t now, but I’d at least like to investigate what it would take to do the work before I cover the wings. That will go on today’s list.

Butt ribs are a pain in the…

Today was butt ribs day. It is suggested in the manual that once you attach the wings, you take that opportunity to attach the butt ribs to the fuselage. These ribs basically trim out the transition from the wing to the fuselage. They aren’t structural so it is really just a matter of lining things up and putting them in place permanently.

The instructions were, “Install inboard slats and tape them in place. Open wing slightly, mark where butt ribs go, cut, drill, rivet. Done. Since it was supposed to be 100 degrees (in June?!) we got to work about 6:30am. That was fine for me because I’d already been up several hours. For the boys, there was some pain associated but they never uttered a complaint.

We rolled the airplane outside, then decided to take the rear stand off so the plane could roll on the newly installed tailwheel. It rolls really nicely, as in I can imagine myself taxing this thing and I’m excited. The locking pin isn’t unlocking as I’d like but I’ll see if I can tweak that. We unfolded the wings and then rolled the plane under a large willow oak tree in the yard.

Plane outside under a shade tree, ready to be worked on
Plane outside under a shade tree, ready to be worked on

The boys took all the previously removed tail feathers and swapped them for the slats that had been tucked away since coming back from Robby’s. Once we figured out which slats were inboard and which were outboard, we went outside to tape them to the wings.

As soon as I got to the wing, my stupidity was obvious. I’d read the instructions to tape the slats to the wings as in, hold them in place, put some tape on them, install the butt ribs. When what it meant was, fully install the slats on their dual bearing, hard to install, needs a hydraulic press to press the bolts in, hardware. The pressure was on to get the slats installed before it got too hot. That way we could get the butt ribs installed, then remove the wings and carry the entire project back inside where it would stay for the next month or two.

The slats are specific to where they go, so there is a left and a right, and an inboard and an outboard. We set about fitting out all the hardware and then installed the right slat. The slats were already helpfully labeled by somebody left and right and we’d already figured out the outboard and inboard. With the first slat installed, I tightened down the hardware, fully seating the bearings in place. Then I tried to fold the slat into its stowed position. Nope. What?! I looked at the backside of the slat to see what was hitting. What was labeled as the right slat was actually, and now obviously, the left. I looked down at the one labeled left and saw it only fit the right side. Argh! They had been mislabeled!

The hardware was next to impossible to get in place and now we had to remove it. What ensued was a break for the boys while I went as far as driving to the machine shop to get ideas. Fire, ice, welding, all the normal things were suggested. I had to keep telling them that this wasn’t a tractor, we couldn’t do stuff like that. Eventually we circled around to slide hammers (I own one) and using vice grips to grab the head of the bolt and using the slide hammer to grab the vice grips and pull the whole thing out. I drove back home, setup as suggested, and with Spork’s help and some banging, we removed the offending bolt so we could get the hardware all back in one complete set (they are matched to each side). We ruined the AN4 20A bolt in the process but that was a small price to pay.

With the slat now removed, and the temperature around 95 degrees, we folded the wings and rolled the whole project back inside, defeated, to await another day.

So what do you do with two boys on a 100 degree day when they are supposed to be doing airplane stuff?

Boys washing the Citabria
Boys washing the Citabria

You take them to the airport to wash an airplane, that’s what. We pulled the Citabria out of the hanger and wheeled it over to a patch of grass where we could kick off our shoes and have some fun. It isn’t a big airplane and it doesn’t take that long to clean. Plus it was covered in bugs from the last few flights that I had taken (one with Cody on his first flight!) so I had some ownership of its condition. There was a bit of spraying each other and general horseplay. The plane looked shiny new when we got done in about 30 minutes. Everyone was pleasantly damp and we hopped back in the truck to take Cody to meet his dad for a trip they have this week.

Wednesday will be a no airplane day and then Spork and I will be back on it on Thursday. We have a lot to do, ELT installation including mounting the antennae, making a battery box from scratch and then installing it. Installing the battery itself and it’s wiring, getting the slats mounted, correctly this time, installing the fuel lines, and finishing painting the spoilers. The idea is to have the airplane ready to install the butt ribs when Cody gets back, then start on the fabric covering. That way we’ll hopefully roll through the fabric covering over the next several weeks, getting the plane basically covered. Once that is done, it is onto painting. Somewhere in that process the avionics will show up, meaning it is time to install the instrument panel and do all the associated wiring.

I’ve also ordered the shocks and engine, meaning once the fuselage comes off the stands after covering and painting, it will go onto the tires and stay there. A covered, painted, roll around airplane is deceptively close to being a ready to fly airplane.

With both boys helping, things are moving quickly and I hope covering goes well. We could be painting in a few weeks at this pace.

When I first looked at this project, I was daunted by the amount of work needed to complete an airplane. Now I’m looking at the number of projects left, all of which are significant, and thinking yeah, we’ll be done ahead of schedule. Sun N Fun 2019 is April 2-7th next year and our goal is to be there with this airplane. That is completed and the 40 hours Phase 1 time period flown off. Since I normally fly about 150-200 hours per year, that is a large amount of time to fly. We’ll see.
